Help needed to finish the configuration

General Discussion
1

Hi!

I have some basic experience with nginx but now I need help to debug this configuration.

The logic is ported from Apache’s .htaccess file and it was working for years and for sure I did something wrong while porting it to nginx. Everything works as expected except the part with watermark which is just ignored.

The idea is to intercept requests to /photos/*.jpg and let the PHP file generate the result while URL does not change to client that made a request.
The location of photo files on actual machine is /var/www/vintagezagreb.net/photos/.

Example:
Request: https://vintagezagreb.net/photos/fe6a89c3-6069-6497-4f94-b42d70803f1f.jpg
The result: https://vintagezagreb.net/watermarked.php?file=fe6a89c3-6069-6497-4f94-b42d70803f1f.jpg

Thanks!

# go away from "http"
server {
    if ($host = www.vintagezagreb.net) {
        return 301 https://$host$request_uri;
    } # managed by Certbot

    if ($host = vintagezagreb.net) {
        return 301 https://$host$request_uri;
    } # managed by Certbot

    listen               80;
    listen               [::]:80;
    server_name          vintagezagreb.net www.vintagezagreb.net;
    server_tokens        off;
    client_max_body_size 20M;
    return               301 https://vintagezagreb.net$request_uri;
}

# remove "www"
server {
    listen               443 ssl;
    listen               [::]:443 ssl;
    server_name          www.vintagezagreb.net;
    server_tokens        off;

    add_header           Strict-Transport-Security "max-age=31536000; includeSubDomains; preload" always;
    client_max_body_size 20M;
    return               301 https://vintagezagreb.net$request_uri;

#    ssl_certificate ...
#    ssl_certificate_key ...
}

# main configuration for SmijSe
server {
    listen 443 ssl;
    listen [::]:443 ssl;
    server_name vintagezagreb.net;

    root /var/www/vintagezagreb.net;   # matches your extracted files
    index index.php;

    server_tokens off;
    client_max_body_size 20M;

    # Security headers
    add_header Referrer-Policy origin always;
    add_header X-Content-Type-Options "nosniff" always;
    add_header X-XSS-Protection "1; mode=block" always;
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains; preload" always;

    # Logging
    access_log /var/log/nginx/php-access.log;
    error_log /var/log/nginx/php-error.log;

    # Gzip
    gzip on;
    gzip_min_length 512;
    gzip_proxied expired no-cache no-store private auth;
    gzip_types text/plain application/xml text/css application/javascript application/json;

    # PHP-FPM
    location ~ \.php$ {
        include snippets/fastcgi-php.conf;
        fastcgi_param HTTP_PROXY "";
        fastcgi_pass unix:/run/php/php8.4-fpm.sock;
    }

    # Protect .ht* files
    location ~ /\.ht {
        deny all;
        return 403;
    }

    # Static files caching
    location ~ \.(gif|ico|jpg|png|svg|js|css|htm|html|mp3|mp4|wav|ogg|avi|ttf|eot|woff|woff2)$ {
        allow all;
        expires 1h;
        add_header Pragma public;
        add_header Cache-Control "public";
    }

    # watermark
    location ~ ^/photos/(.*)\.jpg$ {
        try_files /watermarked.php?file=$1 =404;
# tried also with `.jpg` suffix which way my 1st choice
#        try_files /watermarked.php?file=$1.jpg =404;
    }

    # allow short URL without `/photos/`
    rewrite "^/([0-9a-f]{8}(-[0-9a-f]{4}){3}-[0-9a-f]{12})$" /photos/$1 permanent;

    # photo page
    location ~ "^/photos/([0-9a-f]{8}(-[0-9a-f]{4}){3}-[0-9a-f]{12})$" {
        rewrite ^/photos/([0-9a-f\-]+)$ /photo.php?id=$1 last;
    }

    # story page
    location ~ "^/stories/([0-9a-f]{8}(-[0-9a-f]{4}){3}-[0-9a-f]{12})$" {
        rewrite ^/stories/([0-9a-f\-]+)$ /story.php?id=$1 last;
    }

    # tag page
    location ~ ^/tags/(.+)$ {
        rewrite ^/tags/(.+)$ /tag.php?tag=$1 last;
    }

    # favicon
    location = /favicon.ico {
        rewrite ^ /favicon/favicon.ico last;
    }
    location = /safari-pinned-tab.svg {
        rewrite ^ /favicon/safari-pinned-tab.svg last;
    }
    location = /browserconfig.xml {
        rewrite ^ /favicon/browserconfig.xml last;
    }
    location = /manifest.json {
        rewrite ^ /favicon/manifest.json last;
    }
    rewrite ^/apple-touch-(.*)\.png$    /favicon/apple-touch-$1.png    last;
    rewrite ^/android-chrome-(.*)\.png$ /favicon/android-chrome-$1.png last;
    rewrite ^/mstile-(.*)\.png$         /favicon/mstile-$1.png         last;
    rewrite ^/favicon-(.*)\.png$        /favicon/favicon-$1.png        last;

#    ssl_certificate ...
#    ssl_certificate_key ...
}
2

Oh my! I fixed it. Added this at the very end of last server block. It took few hours of my life.

    # watermark
    rewrite ^/photos/(.*)\.jpg$         /watermarked.php?file=$1.jpg   last;
3

This topic was automatically closed 2 days after the last reply. New replies are no longer allowed.
